Description
Part Number: BM320
A sophisticated, full colour LCD monitor that accurately displays a battery’s total capacity, overall health and general status. Ideal for camper trailer and caravan interiors.
FEATURES & SPECS
2.4” COLOUR LCD SCREEN
High intensity LCD screen displays: predicted state of charge, battery health, time to full charge and time to empty.
INSTALLATION KIT
Kit includes 500 Amp shunt and terminals for professional installation.
TOTAL USER CONTROL
Easy to use and navigate buttons provide the user total control and the ability to program low battery capacity and battery health alarms.
1.5M PRE-WIRED HARNESS
Supplied pre-wired with 4 pin connector into the rear of the unit. A separate terminal block provides a further wiring option.
EASE OF FITMENT
Easy and secure surface mount installation via supplied ‘click-fit’ mounting bracket enabling fixture to any surface.
SPECIFICATIONS
|
|---|
| PART NO. | BM320 |
| CURRENT DRAW | 12V/1.5mAdc |
| INPUT VOLTAGE RANGE | 6.0–17.0Vdc |
| MAX CURRENT | 320A |
| BATTERY CAPACITY SUPPORTED | 5-320AH |
| DISPLAY RESOLUTION | Current: 0.1A |
| Voltage: 0.1V |
| Battery Capacity: 0.1Ah |
| TYPE OF BATTERY SUPPORTED | Wet/AGM/Gel/Calcium |
| CABLE LENGTH | 1.5m |
| CONNECTORS | Terminal Block |
| Molex 4 pin snap fit |
| DISPLAY |
| TIME REMAINING (to full/to empty) |
| POWER REMAINING (Ah) |
| CHARGING/DISCHARGING STATUS |
BATTERY STATE OF HEALTH
(Ideal, Good, Fair, Poor)
|
| PROTECTION |
| MINIMUM VOLTAGE | 6V |
| INPUT OVER VOLTAGE PROTECTION | 17V |
| REVERSE POLARITY PROTECTED |
