Description
Part Number: 2RL010979201
Long service life: No moving parts, no wear and maximum reliability providing long design life and low life cycle costs. Based on the proven and successful design of the RotaLed, the increased IP Rating enabled the OptiRay to be used in even the harshest environments with frequent high-pressure cleaning. Since LEDs are maintenance-free, they do not cause any additional costs for spare parts or maintenance. Down-times are reduced to a minimum. Vibration resistant, OptiRay are optimally protected against vibrations and jolting through the use of LED technology. Innovative electronics concept makes a rotary or flashing function possible without moving parts. Flat compact design and impact-resistant dome made of polycarbonate protect the light from impact. Two different attachment variants guarantee surface-mounted solutions for every application.
Other Details:
| Voltage | 10-32V |
|---|
| Current Consumption | Rotating: @ 0.8A (12V) & @ 0.4A (24V)
Flashing: @ 0.7A (12V) & @ 0.35A (24V) |
| Power Consumption | Rotating: 10W
Flashing: 12W |
| Dome Lens | Polycarbonate |
| Housing | EPDE Rubber |
| IP Rating | IP6K7, IP6K9K |
Operating
temperature | -40°C to 60°C |
Reverse polarity
protection | Yes |
EMC interference
immunity | ECE-R10 |
| Type Approval | SAE J845 class 2 (OptiRAY 2.0 only) |
ECE R65
Compliance
OptiRay 2.0 Rotating | Amber: TA1 E1 R65 00 3109
Blue: TB1 E1 R65 00 3503 |
ECE R65
Compliance
OptiRay 2.1 Flashing | Amber: TA1 E1 R65 00 4154
Blue: TB1 E1 R65 00 4155
Red: TR1 E1 R65 00 4255 |
