Description
Part Number: 2431
Jumbo-S LED stop, rear position, rear direction indicator and reversing lamp with 23cm² redretro reflectors. Lamps are pre-assembled and wired into housing for easy installation. Features HCS Technology with ISO 13207-1 compliance.
Other Details:
| 2431 |
2VP 980 760-821 |
| 2431-CS |
2VP 980 761-821 HCS TECHNOLOGY - 24V ONLY |
| Mounting |
Surface mount with mounting bolts supplied.
Suitable for horizontal or vertical mounting. |
| Voltage |
Multivolt for optimum brightness in 12 and 24 volt systems. |
| Power Consumption |
Stop 5W
Rear position: 1W
Rear direction indicator: 4W
Reversing: 4W |
| Protection |
Reverse polarity and 5000 watt Transient Voltage Suppressor (TVS)
IP 6K7 (Protection against dust and temporary water immersion)
IP 6K9K (Protection against dust and high-pressure/steam jet cleaning) |
| Cable Length |
Pre-wired with 2m of sheathed multi-core cable. |
| Compliance |
ADR 1/00 ADR 6/00: Cat 2a ADR 47/00
ADR 49/00 ISO 13207-1 (2431-CS only) RCM Compliant |
