Description
Part Number: IDC25
A truly sophisticated dual battery management system ideal for 4WD and camper trailer applications. Provides an advanced 3 stage charge simultaneously from both solar and alternator inputs.
FEATURES & SPECS
ENGINE BAY INSTALLATION
Sealed to IP67, the IDC is dust, splash and shock proof and can safely operate in extreme temperatures up to 80°C.
DUAL CHARGING MODES
Engineered to work with both smart and conventional alternators.
MULTI-CHEMISTRY
Set the charging profile to suit battery chemistry type: Wet, Calcium AGM or Gel.
DUAL INPUT OPERATION
Simultaneous dual battery charging from both solar and alternator inputs.
TOTAL SAFEGUARD PROTECTION
Over temperature, reverse connection, over/under and spark free protection.
SPECIFICATIONS
|
---|
PART NO. | IDC25 |
CHARGE TYPE | 3 Stage |
ALTERNATOR INPUT VOLTAGE | 9-32Vdc |
MAX SOLAR INPUT | 23Vdc, 385W |
OUTPUT CURRENT | Input 9-11Vdc 20A, Input 11-32Vdc 25A |
BACK DRAIN ON AUX BATTERY | 9.5-10.5mA |
CHARGER CONTROL | Gel: 14.1V AGM: 14.4V Wet: 14.7V Calcium: 15.4V |
BATTERY CAPACITY | 75-300Ah |
BATTERIES SUPPORTED | Gel, AGM, Wet & Calcium |
SMART ALTERNATOR | 12V Vehicle Turn On: 12.2-20V Turn Off: <11.9V
| 24V Vehicle Turn On: 24.4-32V Turn Off: <24V
|
CONVENTIONAL ALTERNATOR | 12V Vehicle Turn On: 13.4-20V Turn Off: <12.8V
| 24V Vehicle Turn On: 26.8-32V Turn Off: <25.6V
|
OPERATING TEMPERATURE | -10C° to +80C° |
