Description
Part Number: HDBM4000
Perfect for the modern professional workshop, the Battery Manager has the power and functions needed for today’s high tech vehicles. Engineered and manufactured by leading European charger specialist Telwin, it boasts the very latest in battery management. Supplied standard with removable leads and the option of extended leads if needed.
FEATURES
Multi-Voltage Operation
Adjustable to suit 6, 12 or 24 Volt operation
Customise Charge Profile
Adjustable output for different battery sizes and chemistry type selection to suit Wet, Calcium, AGM and Gel
Testing & Diagnostics
Sophisticated functions to accurately test a vehicles alternator for faults, starting capacity as well as measure voltage levels
Engine Start
Delivers a fast charge of 70A for 3 seconds (30 sec cycles) to start vehicles with a flat battery (subject to battery condition)
Power Supply Mode
Maintains constant voltage allowing vehicle diagnostics or to retain settings during battery replacement
| SPECIFICATIONS |
| TYPE |
8 Stage Automatic |
| INPUT |
240V, 50Hz, 600W |
| OUTPUT |
3–40A at 6V
3–40A at 12V
3–20A at 24V |
| ENGINE START |
12V only 70A for 3 secs |
| CHARGE CONTROL |
6V / 12V / 24V
Auto: 7.2V / 14.4V / 28.8V
Auto•: 7.7V / 15.4V / 30.8V
Gel: 7.2V / 14.4V / 28.8V
AGM: 7.35V / 14.7V / 29.4V
Wet: 7.7V / 15.4V / 30.8V
Calcium: 8.0V / 16.0V / 32.0V |
| FLOAT VOLTAGE |
6.7V 13.5V 27.0V |
| MINIMUM START VOLTAGE |
2.0V |
| BACK DRAIN |
20mA 50mA 80mA |
| APPROVALS |
Electrical Safety, EMC |
| BATTERY CHARGE TIMES |
| HDBM4000 |
6 & 12V
BATTERY
RANGE |
24VBATTERYRANGE |
CHARGE
TIME |
| AUTOMOTIVE (CCA) |
100–3700 |
100–2000 |
6–15 hrs |
| MARINE (MCA) |
120–4600 |
120–2300 |
8–18 hrs |
| DEEP CYCLE (AH) |
14–600 |
14–300 |
7–17 hrs |
